ABL-16.000MHZ-B2-I-T,进口无源晶振,Abracon插件晶振,HC-49/US谐振器,ABL石英晶体
| 型号名称Model name： | ABM8 | 品牌 brand ： | ABRACON |
| 原厂型号Original model ： | ABL-16.000MHZ-B2-I-T | 尺寸size ： | 11.50mm x 5.00mm |
| 产品类型Product type： | MHz Crystal | 高度 Package Height： | 3.50mm |
| 频率frequency ： | 16MHz | 工作温度Operating Temperature ： | -20℃~70℃ |
| 频率公差Tolerance ： | ±20ppm | 等效串联电阻 ESR ： | 40 Ohms |
| 负载电容 Load capacitance ： | 18pF | 包装类型Packaging Type : | HC-49/US |
| 产地Origin： | 欧美晶振 | 制造商Manufacturer ： | ABRACON |
| 安装方式Installation ： | Through Hole | 最小包装数 MPQ ： | 1000 / reel |
ABL-16.000MHZ-B2-I-T,进口无源晶振,Abracon插件晶振,HC-49/US谐振器,ABL石英晶体
| ABL-16.000MHZ-B2-I-T | ABRACON | ABL | MHz Crystal | 16MHz | ±20ppm | 18pF | 40 Ohms |
| ABL-16.128MHZ-B2 | ABRACON | ABL | MHz Crystal | 16.128MHz | ±20ppm | 18pF | 40 Ohms |
| ABL-11.0592MHZ-B4Y-T | ABRACON | ABL | MHz Crystal | 11.0592MHz | ±30ppm | 18pF | 50 Ohms |
| ABL-11.2896MHZ-B4Y-T | ABRACON | ABL | MHz Crystal | 11.2896MHz | ±30ppm | 18pF | 50 Ohms |
| ABL-12.000MHZ-B4Y-T | ABRACON | ABL | MHz Crystal | 12MHz | ±30ppm | 18pF | 50 Ohms |
| ABL-13.560MHZ-B4Y-T | ABRACON | ABL | MHz Crystal | 13.56MHz | ±30ppm | 18pF | 50 Ohms |
| ABL-14.31818MHZ-B4Y-T | ABRACON | ABL | MHz Crystal | 14.31818MHz | ±30ppm | 18pF | 50 Ohms |
| ABL-18.432MHZ-B4Y-T | ABRACON | ABL | MHz Crystal | 18.432MHz | ±30ppm | 18pF | 40 Ohms |
| ABL-19.200MHZ-B4Y-T | ABRACON | ABL | MHz Crystal | 19.2MHz | ±30ppm | 18pF | 40 Ohms |
| ABL-20.000MHZ-B4Y-T | ABRACON | ABL | MHz Crystal | 20MHz | ±30ppm | 18pF | 40 Ohms |
| ABL-22.1184MHZ-B4Y-T | ABRACON | ABL | MHz Crystal | 22.1184MHz | ±30ppm | 18pF | 40 Ohms |
| ABL-27.000MHZ-B4Y-T | ABRACON | ABL | MHz Crystal | 27MHz | ±30ppm | 18pF | 100 Ohms |
| ABL-3.6864MHZ-B4Y-T | ABRACON | ABL | MHz Crystal | 3.6864MHz | ±30ppm | 18pF | 180 Ohms |
| ABL-35.328MHZ-B4Y-T | ABRACON | ABL | MHz Crystal | 35.328MHz | ±30ppm | 18pF | 40 Ohms |
| ABL-4.000MHZ-B4Y-T | ABRACON | ABL | MHz Crystal | 4MHz | ±30ppm | 18pF | 180 Ohms |
| ABL-4.096MHZ-B4Y-T | ABRACON | ABL | MHz Crystal | 4.096MHz | ±30ppm | 18pF | 180 Ohms |
| ABL-4.9152MHZ-B4Y-T | ABRACON | ABL | MHz Crystal | 4.9152MHz | ±30ppm | 18pF | 180 Ohms |
| ABL-50.000MHZ-B4Y-T | ABRACON | ABL | MHz Crystal | 50MHz | ±30ppm | 18pF | 40 Ohms |
| ABL-7.680MHZ-B4Y-T | ABRACON | ABL | MHz Crystal | 7.68MHz | ±30ppm | 18pF | 100 Ohms |
| ABL-8.000MHZ-B4Y-T | ABRACON | ABL | MHz Crystal | 8MHz | ±30ppm | 18pF | 80 Ohms |
| ABL-8.912MHZ-B4Y-T | ABRACON | ABL | MHz Crystal | 8.912MHz | ±30ppm | 18pF | 80 Ohms |
| ABL-12.288MHZ-B1U-T | ABRACON | ABL | MHz Crystal | 12.288MHz | ±10ppm | 18pF | 50 Ohms |
| ABL-14.31818MHZ-B1U-T | ABRACON | ABL | MHz Crystal | 14.31818MHz | ±10ppm | 18pF | 50 Ohms |
| ABL-14.7456MHZ-B1U-T | ABRACON | ABL | MHz Crystal | 14.7456MHz | ±10ppm | 18pF | 50 Ohms |
| ABL-16.384MHZ-B1U-T | ABRACON | ABL | MHz Crystal | 16.384MHz | ±10ppm | 18pF | 40 Ohms |
| ABL-18.432MHZ-B1U-T | ABRACON | ABL | MHz Crystal | 18.432MHz | ±10ppm | 18pF | 40 Ohms |
| ABL-20.000MHZ-B1U-T | ABRACON | ABL | MHz Crystal | 20MHz | ±10ppm | 18pF | 40 Ohms |
| ABL-22.000MHZ-B1U-T | ABRACON | ABL | MHz Crystal | 22MHz | ±10ppm | 18pF | 40 Ohms |
| ABL-25.000MHZ-B1U-T | ABRACON | ABL | MHz Crystal | 25MHz | ±10ppm | 18pF | 100 Ohms |
| ABL-26.000MHZ-B1U-T | ABRACON | ABL | MHz Crystal | 26MHz | ±10ppm | 18pF | 100 Ohms |
| ABL-27.000MHZ-B1U-T | ABRACON | ABL | MHz Crystal | 27MHz | ±10ppm | 18pF | 100 Ohms |
| ABL-30.000MHZ-B1U-T | ABRACON | ABL | MHz Crystal | 30MHz | ±10ppm | 18pF | 100 Ohms |
| ABL-60.000MHZ-B4Y-T | ABRACON | ABL | MHz Crystal | 60MHz | ±30ppm | 18pF | 80 Ohms |
| ABL-64.000MHZ-B4Y-T | ABRACON | ABL | MHz Crystal | 64MHz | ±30ppm | 18pF | 80 Ohms |
| ABL-48.000MHZ-B1U-T | ABRACON | ABL | MHz Crystal | 48MHz | ±10ppm | 18pF | 40 Ohms |
| ABL-32.000MHZ-B2 | ABRACON | ABL | MHz Crystal | 32MHz | ±20ppm | 18pF | 80 Ohms |
| ABL-8.192MHZ-B2 | Abracon | ABL | MHz Crystal | 8.192MHz | ±20ppm | 18pF | 80 Ohms |
| ABL-10.000MHZ-B4Y-T | ABRACON | ABL | MHz Crystal | 10MHz | ±30ppm | 18pF | 50 Ohms |
| ABL-12.288MHZ-B4Y-T | ABRACON | ABL | MHz Crystal | 12.288MHz | ±30ppm | 18pF | 50 Ohms |
| ABL-15.360MHZ-B4Y-T | ABRACON | ABL | MHz Crystal | 15.36MHz | ±30ppm | 18pF | 50 Ohms |
| ABL-16.384MHZ-B4Y-T | ABRACON | ABL | MHz Crystal | 16.384MHz | ±30ppm | 18pF | 40 Ohms |
| ABL-22.000MHZ-B4Y-T | ABRACON | ABL | MHz Crystal | 22MHz | ±30ppm | 18pF | 40 Ohms |
ABL-16.000MHZ-B2-I-T,进口无源晶振,Abracon插件晶振,HC-49/US谐振器,ABL石英晶体
